18T Dropside

HIRE A 18T DROPSIDE

18t-Dropside-2016

Close ×

SPECIFICATION

Chassis Type: DAF CF65 290 4x2 Sleeper cab
Body Type: Dropside
GVW: 18 tonnes
Est Payload +/- 5%: 12290kg

DIMENSIONS

Body Bed Length: 8534mm
Body Bed Width: 2286mm
Body Bed Height: 406mm
Wheelbase: 6900mm

KEY FEATURES

  • Galvanised Steel 3mm bearers and 5mm runners

  • Bearers at 406mm centre bolted to all runners

  • Subframe half bearer fitted over rear wheels to maintain 406mm bearer pitch.

  • Angled cleats fitted on every bearer with floor joints

  • Rope hooks bolted to every bearer

  • Galvanised steel side raves 142mm x 50mm x 5mm
  • Cab height galvanised steel headboard frame (75mm x 50mm angle) with 75mm x 50mm full length supports

  • 2 pairs galvanised steel rope hooks bolted to front of headboard

  • Hinged anodised aluminium side guards

  • All lighting to be either Trucklite or Rubbolite LED “plug & play” system with a minimum of 2 LEDs per light

  • Rear top & side LED outline marker light to be protected by loop wiring

  • LED number plate light fitted to rear
  • Rear of lights protected with aluminium plate

  • Aluminium rear closure over chassis ends

  • ECE 104 high conspicuity tape to the side & cab in white & the rear in red

  • Water test body

  • NSSTA certification

  • Conspicuity markings cab & body to regulation ECE104

DOWNLOAD PDF SPECIFICATION
